MOTOROLA ONE 5G ACE * RF SAFE® Radio Frequency Safe

MOTOROLA ONE 5G ACE Radiation Levels

[add_sar_ranking_update]

Add to Compare Compare

Select a phone to compare SAR levels to other popular phones

Cell Phone Usage & Radiation Exposure

MOTOROLA ONE 5G ACE Safety Tip:

How Much Will Turning Off Wi-Fi and Bluetooth Reduce Radiation?

This SAR chart reveals how turning off Wi-Fi and Bluetooth on your MOTOROLA ONE 5G ACE can significantly reduce your exposure to radiation. Our SAR comparison chart shows that by simply turning off Wi-Fi and Bluetooth transmitters, you can lower the RF radiation exposure to your head by 25.3%, and you can lower exposure to the body by 6.5%, when considering these differences between cellular-only (Wi-Fi/Bluetooth OFF) and simultaneous use exposure (Wi-Fi/Bluetooth ON), a wise way to reduce excessive phone radiation is to tap off unnecessary transmitters when not in use! Additionally, when using your phone as a hotspot, turning off Bluetooth can reduce your exposure by up to 11.2% according to the FCC SAR report for device number IHDT56ZF2.

MOTOROLA ONE 5G ACE SAR Levels

Comparison of SAR levels between cellular-only and simultaneous exposure
Cellular Only	(% DIFF)	Wi-Fi + Cellular
1.18 W/kg	HEAD 25.3%	1.58 W/kg
1.43 W/kg	BODY 6.5%	1.53 W/kg
1.43 W/kg	HOTSPOT 11.2%	1.59 W/kg

Key Takeaways

Children vs Adults: Children have higher SAR levels due to thinner skulls and developing tissues, making them more vulnerable to radiation.
Wi-Fi Impact: Simultaneous use of cellular and Wi-Fi transmission increases SAR levels for all age groups.
Precautionary Measures: Using radiation protection products like QuantaCase can help mitigate these risks, especially for younger users.

By understanding these differences, parents and guardians can make informed decisions to better protect their children from excessive microwave radiation exposure, emphasizing the need for safer smartphone usage practices and protective accessories like QuantaCase.

Children vs Adults Radiation Exposure

The Specific Absorption Rate (SAR) of a mobile device measures the amount of radio frequency energy absorbed by the body during device usage.

The SAR values for the one-5g-ace (FCC ID IHDT56ZF2) are as follows:

1.18 W/kg when held at the head with cellular transmission only
1.43 W/kg when worn on the body with cellular transmission only
1.43 W/kg when used as a Hotspot or Airplay
1.58 W/kg when held at the head with simultaneous cellular and Wi-Fi transmission
1.53 W/kg when worn on the body with simultaneous cellular and Wi-Fi transmission
when used as a Hotspot simultaneously with other transmitters active.

SAR Levels
Overview
QuantaCase™
FCC SAR Report Image

MOTOROLA ONE 5G ACE - SAR Levels

FCC SAR Levels

FCC Approval Date This is the date the phone SAR test was completed before the phone's release to the public as required by law.
04 December 2020
FCC ID The FCC ID is the code used to register a device for FCC compliance
IHDT56ZF2
FCC Report Link A direct link to the FCC's website for confirming SAR levels that are listed on our website - We did the homework for you!
FCC Specific Absorption Rate (SAR) Report For Manufacturer Submitted Model
US SAR Ratings USA Legal Limit is 1.6 W/kg
USA Legal Limit is 1.6 W/kg - FCC SAR testing is measured in watts per kilogram (or W/kg) averaged over ONE gram of simulated biological tissue.
Head SAR Level SAR test when held against your head when only using cellular service. Wifi and other transmitter are NOT active
1.18 W/kg
Body SAR Level SAR test when held against your body only using cellular service. Wifi and other transmitter are NOT active
1.43 W/kg
Product Specific Use SAR test when held against your body only using the phone as a hotspot. Cellular and other transmitter are NOT active
1.43 W/kg
Simultaneous Transmission The highest possible SAR recorded with ALL transmitters active, Cellular, WiFi, and Hotspot
1.59 W/kg
Simultaneous Head The highest possible SAR test when held against your HEAD with cellular and WiFi transmitters active,
1.58 W/kg
Simultaneous Body The highest possible SAR test when held against your BODY with cellular and WiFi transmitters active,
1.53 W/kg
Hotspot SAR The highest possible SAR test when held against your BODY using the phone as a hotspot with cellular and WiFi transmitters active,
1.59 W/kg

EU SAR Level

EU SAR Ratings
European Legal Limit is 2.0 W/kg - EU SAR testing is measured in watts per kilogram (or W/kg) averaged over TEN grams of simulated biological tissue.
Head SAR Level
N/A
Body SAR Level
N/A

Network	Technology	GSM / HSPA / LTE / 5G
	2G bands	GSM 850 / 900 / 1800 / 1900
	3G bands	HSDPA 850 / 900 / 1700(AWS) / 1900 / 2100
	4G bands	1, 2, 3, 4, 5, 7, 8, 12, 13, 14, 17, 18, 19, 20, 25, 26, 29, 30, 38, 39, 40, 41, 66, 71
	5G bands	2, 5, 25, 41, 66, 71 Sub6
	Speed	HSPA, LTE-A, 5G

Launch	Announced	2021, January 08
Launch	Status	Available. Released 2021, January 14

Body	Dimensions	166.1 x 76.1 x 9.9 mm (6.54 x 3.00 x 0.39 in)
	Weight	212 g (7.48 oz)
	SIM	Nano-SIM
		Water-repellent coating

Display	Type	IPS LCD, HDR10
	Size	6.7 inches, 108.4 cm² (~85.7% screen-to-body ratio)
	Resolution	1080 x 2400 pixels, 20:9 ratio (~393 ppi density)

Platform	OS	Android 10
	Chipset	Qualcomm SM7225 Snapdragon 750G 5G (8 nm)
	CPU	Octa-core (2×2.2 GHz Kryo 570 & 6×1.8 GHz Kryo 570)
	GPU	Adreno 619

Memory	Card slot	microSDXC (dedicated slot)
	Internal	64GB 4GB RAM, 128GB 6GB RAM

Main Camera	Triple	48 MP, f/1.7, 26mm (wide), 1/2.0″, 0.8m, PDAF 8 MP, f/2.2, 118 (ultrawide), 1.12m 2 MP, f/2.4, (macro), AF
	Features	LED flash, HDR, panorama
	Video	4K@30fps, 1080p@30/60fps, gyro-EIS

Selfie camera	Single	16 MP, f/2.2, (wide), 1.0m
	Features	HDR
	Video	1080p@30fps

Sound	Loudspeaker	Yes
	3.5mm jack	Yes

Comms	WLAN	Wi-Fi 802.11 a/b/g/n/ac, dual-band, Wi-Fi Direct
	Bluetooth	5.1, A2DP, LE
	Positioning	GPS (L1+L5), GLONASS, GALILEO
	NFC	Yes
	Radio	Unspecified
	USB	USB Type-C 2.0

Features	Sensors	Fingerprint (rear-mounted), accelerometer, gyro, proximity, compass, barometer

Battery	Type	Li-Po 5000 mAh, non-removable
	Charging	15W wired

Misc	Colors	Volcanic Gray, Frosted Silver
	Models	XT2113-2
	Price	$ 129.95
